OPL for KiCAD

As a first step toward a fully native KiCad version of the Seeed OPL, we’ve used a script to export the current Eagle library as outlined in the recipe HERE.
This machine-created alpha version is functional but has not been verified so should be used with caution.
s
  • Silkscreen and symbol texts are not yet aligned
  • The Electrical Types for pins are unset in the symbol library so ERC in Eeschema may show unexpected errors
  • 3D models are not yet associated with these components so 3D rederings of your PCB will not show these parts
Please report any issue
the OPL KiCad Volunteers by email to [email protected] and if you’d like to help out we’d love that too. A special thank you to our volunteers (Geoff Steele and Manuel Monteagudo) for their active participation and brilliant contribution.
